3D Robotic laser cutting machine

robot metal laser cutting machine image3

Product Features

It adopts automatic robot motion technology and professional high-precision laser head. The laser output power is stable and the processing width is large. It can be used for sheet metal and stainless steel.

Different thickness metal materials are precisely cut and processed. The automotive industry is its main servicing field. Covers for automotive parts, including cover, back cover, water tank, bumper, fender, door and chassis, ingots, control arms, rear axles, etc., often require three-dimensional cutting, including trimming And punching, etc.

Machine Parameter

Mechanical arm span2010mm
Output laser power1000-4000W Raycus or IPG
Working abutment2000×2000mm (Fixed type)
Axis1±160º
Axis2±147.5º / -130º
Axis3±145º
Axis4±270º
Axis5±140º / -115º
Axis6±360º
Reposition accuracy±0.05mm (VDI/DGQ3441)
Total power11Kw
Gross weight2T
Overall dimension7000×4000×3200 mm
robot laser cutting machinery

gantry or Squat type

The robot arm can be equipped not only with cutting system, but also with welding system, including laser welding, argon arc welding, two-bond welding, etc.

the advantage of robot in metal laser cutting

Flexibility and versatility: 3D robotic laser cutting allows for the cutting of complex shapes and contours in three dimensions. The robotic arm’s flexibility enables it to reach difficult-to-access areas and cut intricate designs, providing manufacturers with greater design freedom and versatility.

High precision and accuracy: Robotic laser cutting systems are capable of achieving extremely high levels of precision and accuracy. The use of advanced sensors and control algorithms ensures that the cuts are consistent and repeatable, resulting in high-quality finished products.

Increased productivity: 3D robotic laser cutting can significantly increase productivity in manufacturing processes. Robots can work continuously without fatigue and can switch between different tasks efficiently, reducing downtime and optimizing production throughput.

Cost-effectiveness: While the initial investment in a robotic laser cutting system may be significant, the long-term benefits can outweigh the costs. Robotic systems reduce labor costs, minimize material waste through precise cutting, and improve overall process efficiency.

Automation and integration: Robotic laser cutting systems can be integrated into automated production lines, improving overall workflow and reducing the need for manual intervention. They can also be programmed to perform various tasks, making them adaptable to different production requirements.

Enhanced safety: 3D robotic laser cutting minimizes the need for human operators to be in close proximity to the cutting process, reducing the risk of injuries associated with traditional cutting methods. Safety measures and interlocking systems further ensure safe operation.

Material handling capabilities: Some robotic laser cutting systems are equipped with additional features, such as material handling and loading/unloading capabilities. This streamlines the manufacturing process and increases overall system efficiency.

Real-time monitoring and quality control: Advanced robotic laser cutting systems can incorporate real-time monitoring and feedback mechanisms to ensure consistent quality throughout the cutting process. Any deviations can be detected and corrected promptly, maintaining high product standards.

Environmental friendliness: Robotic laser cutting is generally more energy-efficient and generates fewer emissions compared to traditional cutting methods, contributing to a more environmentally friendly manufacturing process.

Overall, 3D robotic laser cutting offers numerous advantages for engineers and manufacturers, providing precise, flexible, and cost-effective solutions for cutting complex shapes and components in various industries, including automotive, aerospace, electronics, and more.
